Construction |
Dryback Luxury Vinyl Plank & Tile |
|
Total Thickness |
3mm (0.118'') |
|
Wear Layer |
0.5mm / 20mil |
|
Length |
48.31'' (plank); 24'' (tile) |
|
Width |
7.32'' (plank); 12'' (tile) |
|
Edge Detail |
4-sided Microbevel (plank); Square Edges (tile) |
|
Finish |
Embossed (plank); Marble Surface (tile) |
|
Top Surface |
UV Cured & Ceramic Bead Protection |
|
Installation |
Glued Down |
|
Suitable Location |
On, Above or Below Grade |
|
Radiant Heat |
Hydronic Heated Floor, Max. Temp 25°C |
|
Application |
Residential & Light - Medium Commercial Use |
|
Certification |
FloorScore, ASTM, CE, Phthalates Free |
|
Warranty |
Limited Lifetime Residential, 15-Year Commercial |
|
Fire Rating |
EN 13501-1 |
Bf1-S1 |
ASTM E 648-06 |
Pass / Class 1 |
|
Mekel Burner Test |
Pass |
|||
|
Heat Stability |
KSM 3802 |
0.3mm / 0.01 (80C, 6 hr) |
ASTM F1514 |
Pass |
|
Slip Resistance |
BS 7976-2 Pendulum Test |
Low |
ASTM D 2047-93 |
Pass |
|
Rz Surface Roughness |
Moderate |
|||
|
Residual Indentation |
EN 433 |
≤ 0.1mm |
ASTM F 1914/F 970 |
Pass |
|
Color Fastness |
EN 20105 |
B02 Method A ≥ 6 |
ASTM F 1515 |
Pass |
|
Dimensional Stability |
EN 434 |
≤ 0.25% |
ASTM F 2199 |
Pass |
|
Flexibility |
EN 435 |
No Crack was Found |
ASTM F 137 |
Pass |
|
Electrical Behavior |
EN 1081 |
Pass |
ASTM F 150-06 |
Pass |
|
Chemical Resistance |
EN 423 |
Pass |
ASTM F 925 |
Pass |
|
ASTM F 1344 |
Pass |
|||
|
Toxic Element Test |
EN 71-3 |
Pass |
Does not contain heavy metal and formaldehyde |
|
|
Smoke Density |
ASTM E 662 |
Pass |
|
Pcs Per Carton |
18 Pcs / CTN |
|
|
Cartons Per Pallet |
50 CTN / Pallet (Plank) |
60 CTN / Pallet (Tile) |
|
SF Per Carton |
44.22 SF/ CTN (Plank) |
36 SF / CTN (Tile) |
|
SF Per Pallet |
2,211 SF / Pallet (Plank) |
2,160 SF / Pallet (Tile) |
