Buttershine
Installation Guide
Technical Sheet
Warranty
Care and Maintenance
Product Specifications
| Construction | Dryback Luxury Vinyl Plank |
| Total Thickness | 0.197” (5mm) |
| Wear Layer | 0.55mm / 22mil |
| Length | 48.31” (1227mm) |
| Width | 7.32” (186mm) |
| Edge Detail | 4-sided Microbevel |
| Finish | Embossed Surface |
| Top Surface | UV Cured & Ceramic Bead Protection |
| Fiberglass Layer | Yes |
| Installation | Glued Down |
| Suitable Location | On, Above or Below Grade |
| Radiant Heat | Hydronic Heated Floor, Max. Temp 25°C |
| Application | Residential & Light – Medium Commercial Use |
| Certification | FloorScore, ASTM, CE, Phthalates Free |
| Warranty | Limited Lifetime Residential, 15-Year Commercial |
Technical Data Sheet
| Fire Rating | EN 13501-1 | Bf1-S1 | ASTM E 648-06 | Pass / Class 1 |
| Mekel Burner Test | Pass | |||
| Heat Stability | KSM 3802 | 0.3mm / 0.01 (80C, 6 hr) | ASTM F1514 | Pass |
| Slip Resistance | BS 7976-2 | Pendulum Test: Low | ASTM D 2047-93 | Pass |
| Rz Surface Roughness | Moderate | |||
| Residual Indentation | EN 433 | ≤ 0.1mm | ASTM F 1914/F 970 | Pass |
| Color Fastness | EN 20105: B02 Method A | ≥ 6 | ASTM F 1515 | Pass |
| Dimensional Stability | EN 434 | ≤ 0.25% | ASTM F 137 | Pass |
| Flexibility | EN 435 | No Crack was Found | ASTM F 137 | Pass |
| Electrical Behavior | EN 1081 | Pass | ASTM F 150-06 | Pass |
| Chemical Resistance | EN 423 | Pass | ASTM F 925 | Pass |
| ASTM F 1344 | Pass | |||
| Toxic Element Test | EN 71-3 | Pass. | Does not contain heavy metal and formaldehyde | |
| Smoke Density | ASTM E 662 | Pass |
Packaging Information
| Pcs Per Carton | 12 Pcs / CTN |
| Cartons Per Pallet | 45 CTN / Pallet |
| SQFT Per Carton | 29.48 SQFT/ CTN |
| SQFT Per Pallet | 1,326.6 SQFT / Pallet |
