Description
Product Specifications
| Color Number | 3101 |
| Construction | Dryback Luxury Vinyl Plank & Tile |
| Total Thickness | 3mm (0.118”) |
| Wear Layer | 0.5mm / 20mil |
| Length | 48.31” (plank); 24” (tile) |
| Width | 7.32” (plank); 12” (tile) |
| Edge Detail | 4-sided Microbevel (plank); Square Edges (tile) |
| Finish | Embossed (plank); Marble Surface (tile) |
| Top Surface | UV Cured & Ceramic Bead Protection |
| Installation | Glued Down |
| Suitable Location | On, Above or Below Grade |
| Radiant Heat | Hydronic Heated Floor, Max. Temp 25°C |
| Application | Residential & Light – Medium Commercial Use |
| Certification | FloorScore, ASTM, CE, Phthalates Free |
| Warranty | 1Limited Lifetime Residential, 15-Year Commercial |
Technical Test Data
| Fire Rating | EN 13501-1 Bf1-S1 Mekel Burner Test Pass | ASTM E 648-06 Pass / Class 1 |
| Heat Stability | KSM 3802 0.3mm / 0.01 (80C, 6 hr) | ASTM F1514 Pass |
| Slip Resistance | BS 7976-2 Pendulum Test: Low Rz Surface Roughness: Moderate | ASTM D 2047-93 Pass |
| Residual Indentation | EN 433 ≤ 0.1mm | ASTM F 1914/F 970 Pass |
| Color Fastness | EN 20105: B02 Method A ≥ 6 | ASTM F 1515 Pass |
| Dimensional Stability | EN 434 ≤ 0.25% | ASTM F 2199 Pass |
| Flexibility | EN 435 No Crack was Found | ASTM F 137 Pass |
| Electrial Behavior | EN 1081 Pass | ASTM F 150-06 Pass |
| Chemical Resistance | EN 423 Pass | ASTM F 925 Pass |
| Toxic Element Test | EN 71-3 Pass. Does not contain heavy metal and formaldehyde | ASTM F 1344 |
| Smoke Density | ASTM E 662 Pass |
Packaging Information
| Pcs Per Carton | 18 Pcs / CTN |
| Cartons Per Pallet | 50 CTN / Pallet (Plank); 60 CTN / Pallet (Tile) |
| SF Per Carton | 44.22 SF/ CTN (Plank); 36 SF / CTN (Tile) |
| SF Per Pallet | 2,211 SF / Pallet (Plank); 2,160 SF / Pallet (Tile) |
